Spring 4 MVC Hello World Class Name Handler Mapping Example

July 10, 2015 | Updated last October, 2015 | 1610 views | Comments

Create a Spring WebMVC 4 Hello World app using the Class ControllerClassNameHandlerMapping. Home page, About Page, and Contact Page will be demonstrated in this example.



Built and tested with the following:

  • Eclipse Juno IDE
  • Apache Tomcat 7.0.47
  • JDK 1.7.0
  • Maven 3.0.4
  • Spring Web-MVC Framework 4.2.2
    • Configuration: XML
    • Url Mapping: Class Name Handler



Step 1. Create a new Maven Project.

Set up a new Maven Project with the following details:

  • Group Id: com.consistentcoder
  • Artifact Id: spring-4-mvc-hello-world-class-name-handler-mapping
  • Name: spring 4 mvc hello world class name handler mapping

Tutorials:
Create a New Maven Project in Eclipse
Configure Run on Server option on a Maven Project on Eclipse IDE



Step 2. Edit pom.xml file.

Set up the needed details and the project information to build the project.

<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <groupId>com.consistentcoder</groupId>
    <artifactId>spring-4-mvc-hello-world-class-name-handler-mapping</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <packaging>war</packaging>
    <name>spring 4 mvc hello world class name handler mapping</name>

    <dependencies>
        <!-- Spring Framework -->
        <dependency>
            <groupId>org.springframework</groupId>
            <artifactId>spring-webmvc</artifactId>
            <version>4.2.2.RELEASE</version>
        </dependency>

        <!-- Java Servlet API -->
        <dependency>
            <groupId>javax.servlet</groupId>
            <artifactId>javax.servlet-api</artifactId>
            <version>3.1.0</version>
        </dependency>
    </dependencies>
</project>

/pom.xml



Step 3. Edit web.xml file.

Integrate Spring WebMVC by mapping incoming request to the "DispatcherServlet", do this inside the "Deployment Descriptor".

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns="http://java.sun.com/xml/ns/javaee" xmlns:web="http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd" xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd" id="WebApp_ID" version="3.0">
    <display-name>spring-4-mvc-hello-world-class-name-handler-mapping</display-name>
    <servlet>
        <servlet-name>spring</servlet-name>
        <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
        <load-on-startup>1</load-on-startup>
    </servlet>

    <servlet-mapping>
        <servlet-name>spring</servlet-name>
        <url-pattern>/</url-pattern>
    </servlet-mapping>
</web-app>

/src/main/webapp/WEB-INF/web.xml



Step 4. Create spring-servlet.xml file.

Map the corresponding class controller of an incoming request that will create a model and will return the view file. In this example, three (3) pages should be created. The Home, About, and Contact Pages. Make the Home Class Controller the default page by setting it as the rootHandler.

<beans xmlns="http://www.springframework.org/schema/beans"
    xmlns:context="http://www.springframework.org/schema/context"
    xmlns:mvc="http://www.springframework.org/schema/mvc"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="
    http://www.springframework.org/schema/beans
    http://www.springframework.org/schema/beans/spring-beans-4.2.xsd
    http://www.springframework.org/schema/context
    http://www.springframework.org/schema/context/spring-context-4.2.xsd
    http://www.springframework.org/schema/mvc
    http://www.springframework.org/schema/mvc/spring-mvc-4.2.xsd">

    <!-- ControllerClassNameHandlerMapping -->
    <bean class="org.springframework.web.servlet.mvc.support.ControllerClassNameHandlerMapping">
        <property name="caseSensitive" value="true" />
        <property name="rootHandler" value="homeBean" />
    </bean>
    <bean name="homeBean" class="com.consistentcoder.controllers.Home" />
    <bean class="com.consistentcoder.controllers.About" />
    <bean class="com.consistentcoder.controllers.Contact" />

    <bean class="org.springframework.web.servlet.view.InternalResourceViewResolver">
        <property name="prefix">
            <value>/WEB-INF/jsp/</value>
        </property>
        <property name="suffix">
            <value>.jsp</value>
        </property>
    </bean>
</beans>

/src/main/webapp/WEB-INF/spring-servlet.xml



Step 5. Create the template file.

Set up views files by creating a new folder inside "WEB-INF", name it "jsp". After that, create a new jsp file inside it and name it "hello.jsp", then put the following code inside it.

<%@ page language="java" contentType="text/html; charset=ISO-8859-1"
    pageEncoding="ISO-8859-1"%>
<!DOCTYPE html PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN" "http://www.w3.org/TR/html4/loose.dtd">
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=ISO-8859-1">
<title>Spring 4 MVC Hello World Class Name Handler Mapping Example</title>
</head>
<body>
    <p>
        <ul>
            <li><a href="<%=request.getContextPath()%>">Home Page</a></li>
            <li><a href="<%=request.getContextPath()%>/about">About Page</a></li>
            <li><a href="<%=request.getContextPath()%>/contact">Contact Page</a></li>
        </ul>
    </p>
    <h1>${ message }</h1>
</body>
</html>

/src/main/webapp/WEB-INF/jsp/hello.jsp



Step 6. Create the Controller Class.

Transform and interpret each incoming request into a model. Create a new package and name it "com.consistentcoder.controllers". Create a new class inside it, name the class "Main".

Tutorials:
Create a New Package on Eclipse IDE
Create a New JAVA Class on Eclipse IDE



Step 6.1 Create the Home Page Controller.

Create the class file (Home.JAVA) that is mapped to the Home Page, as described on the file spring-servlet.xml.

package com.consistentcoder.controllers;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import org.springframework.web.servlet.ModelAndView;
import org.springframework.web.servlet.mvc.AbstractController;

public class Home extends AbstractController {
	public ModelAndView handleRequestInternal(HttpServletRequest request,
		    HttpServletResponse response) throws Exception {
		        ModelAndView mv = new ModelAndView();
		        mv.setViewName("hello");
		        mv.addObject("message", "Spring 4 MVC Hello World<br>Class Name Handler Mapping Example");
		        return mv;
		    }
}

/src/main/java/com/consistentcoder/constrollers/Home.java



Step 6.2 Create the About Page Controller.

Create the Controller About.JAVA, check the file spring-servlet.xml for reference.

package com.consistentcoder.controllers;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import org.springframework.web.servlet.ModelAndView;
import org.springframework.web.servlet.mvc.AbstractController;

public class About extends AbstractController {
	public ModelAndView handleRequestInternal(HttpServletRequest request,
		    HttpServletResponse response) throws Exception {
		        ModelAndView mv = new ModelAndView();
		        mv.setViewName("hello");
		        mv.addObject("message", "Hello World - About Page...");
		        return mv;
		    }
}

/src/main/java/com/consistentcoder/constrollers/About.java



Step 6.3 Create the Contact Page Controller.

Create the last needed Controller Contact.JAVA, again as configured on the spring-servlet.xml file.

package com.consistentcoder.controllers;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import org.springframework.web.servlet.ModelAndView;
import org.springframework.web.servlet.mvc.AbstractController;

public class Contact extends AbstractController {
	public ModelAndView handleRequestInternal(HttpServletRequest request,
		    HttpServletResponse response) throws Exception {
		        ModelAndView mv = new ModelAndView();
		        mv.setViewName("hello");
		        mv.addObject("message", "Hello World - Contact Page...");
		        return mv;
		    }
}

/src/main/java/com/consistentcoder/constrollers/Contact.java



That's all!

Spring 4 MVC Hello World Class NameHandler Mapping Example has been developed.



Final Project Structure



What's Next? Test the application.

Start your server and browse this link. http://localhost:8080/spring-4-mvc-hello-world-class-name-handler-mapping/. Home Page will be displayed.



About Page



Contact Page



Note: All various handler/controller beans defined in it's application context will be found by ControllerClassNameHandlerMapping(). Thus, in this example, /about maps to the /about* request URL, and /contact maps to the /contact* request URL.




Reference:

  • http://docs.spring.io/spring/docs/current/spring-framework-reference/html/mvc.html#mvc-coc-ccnhm
